5. XPRESS COOLING
This helps cabin to reach to comfort temperatures
quickly by optimally setting the air conditioning to
maximum cooling. Also, if required, the driver win-
dow will roll down to flush the hot air from inside the
cabin. XPRESS Cooling can be turned On/Off by
Fascia switch or by a soft key from Head Unit.
Location
FUNCTIONALITY
Once Xpress cooling button is pressed, system op-
timally calculates if the car is soaked in sun and
takes the driver’s window roll down to flush out the
hot air from cabin. Also, air conditioning system will
be set to maximum cooling and maximum fan speed
for short duration.
Once cabin has been sufficiently flushed, the system
will announce to take driver window’s roll up which
can be taken up using window winding switch.
Driver side window may roll down, if:
The cabin temperature is more than outside tem-
perature.
If it is not raining.
Vehicle Speed is less than 40 kmph.
Further, after sufficiently cooling the cabin, the
Xpress cooling function will auto switch off and revert
back to customer pre-selected settings.
Express cooling functionality is used to improve the
HVAC system performance.
In case of cabin temperature being considerably
greater than outside air temperature. The system will
be deactivated automatically after 500 sec of contin-
uous operation.
NOTE:
The Express Cool function can only be turned ON if
the Ambient tem-perature is above 18 degree Cel-
sius.
6. HMI CLIMATE CONTRL DISPLAY
It is located on the dashboard.
HMI CLIMATE CONTRL STATUS DISPLAY
The Climate Control feature is vehicle dependent.
The infotainment system displays the following cli-
mate control related information in its display screen
bottom bar.
Display Screen with Climate Control Details in
Footer
Display Screen Climate Information
1.
AC ON/OFF display and control
2.
Blower speed display and control
3.
MAX-Defrost display and control
4.
Air distribution display and control
5.
AUTO ON display
6.
Air inlet(Fresh \ recirculation) display
and control
7.
Temperature display and control
8.
Xpress Cooling
