TRANSAXLE TA6300 AMT
30
11. Drain the Transaxle oil by removing Drain
Plug.
12. Remove earthing cable from gear box.
13. Remove stub axle ball joint Mounting &
Loosen Lower Control Arm on LH & RH side.
14. Remove driveshaft lock nut LH& RH.
15. Remove ball joint (steering rack) from
steering knuckle from both sides.
16. Remove vertical link mountings on
suspension rod for both RH & LH sides.
17. Remove starter motor connection & its three
mountings & take out starter motor.
18. Disconnect electrical connections of Reverse
Light switch.
19. Disconnect power steering pressure line and
its mounting over transaxle.
