1.5L REVOTORQ BS VI ENGINE
143
16. Remove the front mounting bolt of the H.P.
pump.
17. Remove the H.P. pump assembly.
18. Remove the water pump assembly.
19. Remove the timing gear camshaft pulley.
20. Remove the rear timing cover.
21. Remove the crankshaft gear. (
rotate clockwise
to remove the bolt
).
