1.5L REVOTORQ BS VI ENGINE
133
4. Remove the EGR intake and outlet hoses.
5. Remove the dipstick support bracket.
6. Remove the EGR cooler.
7. Remove the H.P. fuel line connected to the fuel
rail.
NOTE
Cover the opening of the fuel rail with suitable
plugs.
Do not reuse the HP pipes once removed; use
new HP pipes at the time of assembly.
8. Remove air intake elbow along with air
temperature sensor.
