1.2L REVOTRON ENGINE
130
12. Remove gudgeon pin from the small end of
connecting rod.
13. Remove connecting rod.
NOTE
Keep each piston and gudgeon pin as a
set, when removed.
14. Using ring expander, remove piston rings
15. Insert flywheel-locking pin to lock flywheel.
16. Remove flywheel mounting bolts and then
flywheel locking pin.
17. Remove Rear oil seal.
18. Turn the bench at 180˚ to remove crankshaft
from bottom side.
