21.7. MICROPHONE (XM - MID)
LOCATION
It is fitted above the driver’s seat on the headlining
REMOVAL
1. Pull out microphone.
2. Disconnect Electrical connection.
3. Take out the microphone.
REFITMENT
For refitment follow the procedure in reverse.
21.8. TWEETERS
Tweeter is a loudspeaker designed to produce high
frequencies
1. LOCATION
There are total four tweeters. Each is fitted inside the
A pillar and rear door.
PINOUT DETAILS
PIN
DESCRIPTION
1
-Ve
2
+ Ve
