BODY
47
2.40 REAR WHEEL ARCH LINER
REAR WHEEL ARCH FRONT
REMOVAL
1. Remove Clip mounting Rear wheel arch liner
front.
2. Remove Push on Nuts as shown in figure.
3. Remove Rear wheel arch front.
FITMENT
For fitment follow reverse procedure of removal.
REAR WHEEL ARCH REAR
REMOVAL
1. Remove Rear Bumper mounting clip.
2. Remove the mounting screw of wheel arch.
3. Remove three Push on Nuts located inside
rear wheel arch.
4. Remove Rear wheel arch rear.
FITMENT
For fitment follow reverse procedure of removal.
