BODY

46

2.39 FRONT WHEEL ARCH LINER

REMOVAL

1. Remove the mounting clip holding front

bumper from bottom wheel arch.

2. Remove mounting push nut and clip.

3. Remove mounting screw located inside the

arch liner.

4. Pull out tree clips.

5. Remove Push on Nuts and mounting screw

clip.

6. Remove front wheel arch liner.

FITMENT

For fitment follow reverse procedure of removal.
