TRANSAXLE - TA5260
56
17. NEUTRAL SETTING PROCEDURE:
NOTE:
Below procedure to be followed after Fixing of Gear
shift and selector cable
1. Fit TA side cable end on ball joint Dia 10 at shift
lever on transmission axle.
2. Fit shifter side cable end on select lever ball.
3. Yellow clip will be in partially fitted condition
before locking the select cable length.
4. Shake lever 4-5 times in direction ( )
of
selection on both side.
5. Press yellow clip of select cable end fitting
(shifter side)
6. Remove neutral setting clip (location in top of
shifter) press snap lug and push it towards rear
of shifter side.
