TRANSAXLE - TA5260
54
9. Loosen the cable grommet nut mounting from
firewall to remove the assembly.
16. ASSEMBLY OF GEAR SHIFTER
HOUSING, GEAR SHIFTER AND
SELECTOR CABLE
:
1. Fit the selector shifter cable over the transaxle
bell crank lever and assembly selector shifter
shaft end
2. Pull and hold the plunger of the transaxle
cable. Then snap fit the cables over the
transaxle cable anchoring bracket.
3. Insert the cable through the firewall and tighten
its mounting on it.
