TRANSAXLE - TA5260
33
Use the open-end spanner 30 mm and turn the
pulling nut clockwise, do not allow anchoring
shaft to turn along with pulling nut.
It will start to pull the bearing out from the
casing.
Turn the pulling nut (30 mm) till the bearing
comes out completely from the casing.
Once the bearing comes out, unlock the
anchoring shaft by turning the locking nut
anticlockwise on the top and slowly tap on the
locking stud down to unlock the bearing from
anchoring body and to remove bearing from the
tool.
24. Remove taper roller bearings Outer Race
using puller part no.
5438 5890 2603
from
housing.
Bearing Outer race removal from Rear Housing
Bearing Outer race removal from Front Housing.
