224 / 1119
1.5L REVOTORQ ENGINE
36
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
25
Gasket (Elbow For EGR Valve To Cyl. Head)
26
Elbow, Air Intake
27
Stud Cm8x25 (Qty. 2)
2.0
28
Hex. Flange Nut Am8 (Qty. 2)
2.0
29
Hex. Flange Nut Am6 (Qty. 3)
1.0 + 0.2
30
Stud C M6x20 (Qty. 3)
1.0 + 0.2
31
Gasket (IC Pipe To Intake Manifold)
32
Water Box
33
Hex. Flange Nut Am6 (Qty. 4)
1.0+0.2
34
Thermostat Assy.
35
Cover, Thermostat
36
Sealing Washer 16x20
37
Temp Sensor
38
Bracket Sensor mtg.
39
H/FL Bolt M6X45
40
Plain_Washer_M6
41
Wave_Sp_Washer_M6
42
Hex FL Screw M6x16
43
Air Temperature Sensor
44
Hex FL Screw M6x16
45
Hex FL Screw M8x20
