1.5L REVOTORQ ENGINE
35
EGR Valve, Thermostat and Components
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
EGR Module Assy
02
Stud C M6x20 (Qty. 2)
03
Hex. Flange Nut Am6 (Qty. 2)
1.0 + 0.2
04
Stud C M6x45 (Qty. 4)
05
Paper Gasket 0.5 Thk
06
Pipe & Hose Assy, TC To Intercooler
07
Hex. Flange Scr M8x14 (Qty. 2)
2 + 0.3
08
Hose Clamp
09
Bracket Assy, EVRV Mtg
10
Hex. Flange Bolt M6x45 (Qty. 4)
1 + 0.2
11
Hose, EVRV To Air Filter
12
Assy. Vacuum Modulator (BS-IV)
13
Hex. Flange Nut Bm6 (Qty. 2)
1 + 0.2
14
Hose, EVRV To T-Connector
15
Hose, EVRV To EGR
16
Hex_Screw_M6X20 (Qty. 2)
2.0
17
Gasket (Elbow For EGR Valve To Cyl. Head)
18
Stud Cm6x25 (Qty. 2)
19
Hex. Flange Nut Am6 (Qty. 2)
1.0 + 0.2
20
Elbow (For EGR Valve)
21
Gasket (Elbow For EGR Valve To Cyl. Head)
22
Gasket (Elbow For EGR Valve To Cyl. Head)
23
EGR Tube Assy
24
Hex. Flange Screw M8x14 (Qty. 2)
2.0 + 0.3
