ALTROZ SERVICE MANUAL

221 / 1119

1.5L REVOTORQ ENGINE
33
Engine Suspension
ITEM
NO.
DESCRIPTION
NO REUSESEALANT
LUBRICATIONTIGHTENING
TORQUE
(kg-m)
01 B-Mount
02 H/Fl Scr M10x25 4 - 4.5
03 Hex. FlangeNut Am12x1.25 4 - 4.5
04 Washer
05 H/Fl Scr M10x25 6.1 – 6.6
06 H/Fl Bolt M10x45 4.5
07 H/Fl Scr M10x25 6.1 – 6.6
08 H/Fl Scr M10x25 6.1 – 6.6
09 A-Mount
10 Bracket,A-Mount Arm
11 H/Fl Bolt M10x50 4.5
12 H/Fl Scr M10x40 6.1 – 6.6
13 Hex Flange Bolt 6.1 – 6.6
14 C-Mount
15 Hex Flange Bolt 10.7 – 11.2
16 Hex. FlangeNut Am12x1.25
17 Bracket,C-Mount
18 Bracket,B-Mount
19 H/Fl Scr M10x30 4.5
20 Hex Flange Bolt 25+/-5
