1.2L REVOTRON ENGINE
90
REMOVAL
1. Loosen and remove the bolt of clamp and
disconnect the two pipe assembly along with
the main silencer from Intermediate pipe.
2. Remove the two rubber hanger.
3. Take out the main silencer assembly.
FITMENT
For fitment follow the reverse procedure of
removal.
INTERMEDIATE EXHAUST ASSY.
REMOVAL
1. Remove the mounting bolts of the Intermediate
exhaust pipe at front.
2. Loosen and remove the bolt of clamp and
disconnect the two pipe assembly along with
the main silencer from Intermediate pipe.
3. Remove all supporting rubber hangers on the
silencer.
4. Remove the Intermediate exhaust assembly.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Use new gaskets every time while fitment
and tighten nuts and bolts to specified
torque.
