1.2L REVOTRON ENGINE
28
Engine Timing :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Fixed Blade
2 Sprocket Crankshaft
3 Hex Pivot Bolt for Chain Guide
(Movable)
2.5
4 Chain
5
Exhaust Camshaft Sprocket To
Camshaft, bolt M12x1.25
•
˚9 ± 5 %
6 Hex FL Bolt M6x25 (2 Qty)
1.0
7 Cam Guide Valve
8 Hex Bolt (Intake Camshaft VVT
•
˚6 ± 0.5
9 Controller Assy, Valve Timing
10 Exhaust Variable Cam Timing
11 Tensioner Guide Rail
12 H/FL Screw M6 x14 (2 Qty)
1.0
13 Hex FL SCR M6X30 (2 Qty)
1.0
14 Tensioner
Note:-
•
This Symbol indicates critical tightening torque.
