1.2L REVOTRON ENGINE
23
Cylinder Block :
Note:-
•
This Symbol indicates critical tightening torque.
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Seal Plug M20x1.5 for oil gallery
crankcase
2.5
2 Crankcase
3 Knock Sensor
4 Hex FL Screw M8X30
2.0+0.5
5 Sealing Plug M24X1.5
3.5
6 Crankshaft Oil Seal (Rear)
7 Hex FL Bolt M8X70 (8Qty)
3.2+0.6
8 Bed plate MB bolt M10 (10 Qty)
•
5.0±0.5 ,
120˚±15˚
9 Bed Plate
10 Crank Angle Sensor
11 H/FL Screw M6X22 for Crank Angle
Sensor
1.0+0.2
12 Deflector Plate Cyl. Block
13 Hollow Dowel,12H6 x10.6 x 12L
14 Hex FL Bolt M8x35
1.0 ± 0.1,
45˚ ± 5˚
15 Balancer Mass
16 Cylindrical Pin
17 Balancer Shaft
18 Thrust Washer
19 CSK Socket Screw M6x20 (2 Qty)
1.2 – 1.5
20 Gear, Balancer Shaft
21 H/FL Bolt M12x45
5.0 ± 0.5,
45˚ ± 5˚
