1.2L REVOTRON ENGINE
26
Moving Parts :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Top Ring
2 Taper Faced Ring
3 Oil Ring
4 Piston Pin
5 Round Wire Circlip
6 Connecting Rod
7 Bearing Half (Connecting Rod)
8 Bolt (Connecting Rod) (M8 X 1) (6 Qty)
•
2.2+0.5
90˚ ± 5˚
9 Woodruff Key
10 Crank Sensor Target Wheel
11 Assembly Vibration Damper Pulley
12 Washer (Damper Pulley)
13 Hex. Bolt M16x1
•
14.5+0.3
90˚ ± 5˚
14 CSK SOC Screw M6X20 for crank sensor wheel
1.7+0.3
15 Bearing Shell Half Lower (Crankshaft)
16 Bearing Shell Half Upper (Crankshaft)
17 Thrust Washer
18 Crankshaft
19 Flywheel
20 Hex. Bolt For Flywheel (M10 X 1.5) (6 Qty)
•
3.5+0.5
25˚ ± 5˚
21 Piston
22 Cylindrical Pin
23 Gear, Crankshaft
24 Cylindrical Pin
25 Bush
