TRANSAXLE - TA5260
27
15. Remove Lower link Assembly mounting on
knuckle.
16. Swing out both drive shafts from transaxle and
hang it suitably with the help of hook 5123
5890 2403.
NOTE:
CARE SHOULD BE TAKEN NOT TO
DAMAGE DRIVESHAFT OIL SEAL AND ITS
BOOTS (DO NOT USE HAMMER).
17. Give proper support to gear box from bottom
side.
18. Remove the hex flange bolt on C- mount of
Transaxle.
19. Remove B-Mount nuts on Gear Box.
20. Remove Clutch housing mountings.
21. Take out gear box from vehicle.
ASSEMBLY OF TRANSAXLE:
Follow the Reverse Procedure for assembly.
