BODY

41

9.2.21 ORVM

REMOVAL

1. Pry out inside cover plate along with Power

mirror switch.

2. Disconnect power mirror switch.

3. Disconnect the electrical connection

4. Open the door to loosen and remove 3

mounting bolts.

5. Remove the ORVM assembly from the door

shell.

FITMENT

For fitment follow the reverse procedure of

removal.
