BODY
45
9.2.26 FRONT SEAT BELT
FOR RETRACTOR PRETENSIONER LOAD
LIMITER (RPLL)
REMOVAL
1. Fold the front seat to have easy access for the
belt removal.
2. Loosen and remove the lower anchorage bolt
of seat belt.
3. Remove front seat belt anchor mounting bolt.
4. Remove the web guide clip by rotating in the
anti-clockwise direction and taking it out from
the guide.
5. Remove lower “B” pillar trim.
(For procedure
refer “B” pillar trim removal procedure in Body
section).
6. Disconnect the electrical connection of RPLL.
7. Loosen and remove the RPLL mounting bolt.
