BODY
44
NOTE
Lift the belts and buckle while removing to ease
the process.
4. Loosen and remove the top seat four mounting
bolts.
5. Tilt the top seat in front to remove it from the 3
hooks on BIW and take out the assembly.
NOTE
Lift the belts and buckle while removing to ease
the process.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Follow the shown sequence of fitment for top seat
mounting bolt.
9.2.25 REAR ROW SEAT ARMREST
REMOVAL
1. Open the trunk lid.
2. Peel open the Velcro carpet opening at the
back of seat to access the mounting bolts of
armrest.
3. Loosen and remove the four mounting bolts.
4. Pull out the armrest from the front and take it
out.
FITMENT
For fitment follow reverse procedure of removal.
