connections as per
the circuit
schematic
3
Are there any pins damaged at EMS ECU Connector or
Brake pedal switch connector?
Replace the
connector or wiring
harness
Go to step 4
4
Are there any pins backed out from the EMS ECU
Connector or Brake pedal switch connector?
Rectify/Replace
Connectors
Go to Step 5
5
Brake Pedal moving freely
Go to next step
Perform necessary
mechanical repairs
6
Check whether the Main Brake Switch / Redundant brake
switch contacts are stuck open
Rectify / Replace
Go to next step
7
Fault Persists?
Call Hot line.
Follow the steps
again for
reconfirmation
DTC’s confirmation:
After rectification, Test Drive the vehicle for 2 KM and ensure that no DTC’s are logged in ECM.
