P0262-2B: Cylinder 1 Injector Circuit High – Short circuit between high side and low side of the power stage
cylinder 1
Overview:
DTC Description (User Friendly)
Short circuit between high side and low side of the power
stage cylinder 1
ECU Pin Number
A85, A64
Customer Symptom
Torque Limited, Cruise Control Off, MIL ON, Abnormal Engine
noise
Fault Effects (On Vehicle)
Reduced torque mode activated, Cruise control off, Abnormal
Engine noise
Lamp Status (If Any)
MIL ON
Fault Detection Condition (Root cause)
Short Circuit btw EMS ECU pins A85 and A64.
Normal Operating Condition
From fault, normal operating condition will be achieved in the
next driving cycle if fault condition is no more present.
Probable Trouble Area
Wiring Harness connections between EMS ECU and Injector
cylinder 1
Injector Cylinder 1
EMS ECU
Healing Condition
Rectify the error
Clear through diagnostic tool
Ignition OFF & ON
Component Details:
Injector is used for, Metering and spray preparation of the diesel fuel, which is needed by the engine
according to the engine map. Realization of pilot and main injection, also post injection, if needed.
Controlling of injected quantity and injection timing, determined by system pressure and energizing time, actuated by the
ECU (Electronic Control Unit).
Preliminary Checks:
1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above
Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.
2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with
respect to earlier issue closure.\
3. Check the wiring harness connections between EMS ECU and Cylinder 1 Injector as per the circuit Schematic.
4. Loose/ Damaged Connections between Cylinder 1 Injector and EMS ECU.
5. Check for damage of pins at EMS ECU connector and Injector cylinder 1 connector.
Trouble Shooting:
Step Checks
IF YES
IF NO
1
Check for any mechanical damage in Cylinder 1 injector
Call Hotline
Go to next step
2
Is there wiring harness electrical continuity between ECU
pin A85 & Cylinder 1 Injector connector pin 2, EMS ECU
pin A64 and Cylinder 1 injector connector pin 1.
Go to next step
Rectify the wiring
harness
connections as per
the circuit
schematic.
3
Check whether the EMS pin A85 and A64 are short-
circuited to each other
Rectify the wiring
harness connections
Go to next step
