Q501 4 Cylinder MT Application

DTC Troubleshooting Data

Version: 0.1

Date: 21-Sep-2018

Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta

Checked By: Yogesh Jadhav

Approved By: Satish Kumar P

Page: 742 of 1052

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

P0219-3A: Engine Over speed Condition – Engine overspeed recognition

Overview:

DTC Description (User Friendly)

Engine over-speed recognition

ECU Pin Number

A020, A021

Customer Symptom

Clutch Slippage might happen

Fault Effects (On Vehicle)

Clutch Slippage might happen

Lamp Status (If Any)

-

Fault Detection Condition (Root cause)

EMS detects Engine speed > 5400 RPM.

Normal Operating Condition

Engine Speed < 5400 RPM

Probable Trouble Area

Driver over-speeding vehicle.

Crank Shaft sensor wiring connections with EMS ECU.

Connector of Crank shaft sensor.

Crank Shaft Sensor

EMS ECU faulty

Healing Condition

Rectify the error

Clear through diagnostic tool

Ignition OFF & ON

Component Details:

This is fitted on the crankcase and faces the phonic wheel on the flywheel. It is inductive type, i.e. its operation is

determined by magnetic field changes generated by the teeth passing in front of the phonic wheel. The changeover from

full to empty determined by the presence or absence of a gap brings about a magnetic flux change sufficient to generate

an induced alternating voltage proportional to the number of teeth on the ring (or phonic wheel). The frequency and

amplitude of the voltage send to the electronic control unit provides the latter with an indication of the engine angular

speed. The sensor output signal approximates a sine wave whose frequency is proportional to engine speed and

amplitude is approximately proportional to engine speed. Active edge is generated from zero crossing point positive to

negative transition.

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned in above

Table. If yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether other customers report similar complaints earlier. If yes, perform the preliminary checks with

respect to earlier issue closure.

3. Driver over-speeding the vehicle.

4. Loose/ Damaged Connections between Crank shaft Sensor and EMS ECU.

5. Check for damage / back out of pins at ECU connector.

6. Check for damage / back out of pins at crank shaft sensor’s connector.

Trouble Shooting:

Step Checks

IF YES

IF NO

1

Is there wiring harness electrical continuity between ECU

pin A020 & Crank Shaft sensor pin 1, ECU pin A021 and

Crank shaft sensor pin 2.

Go to next step

Rectify the wiring

harness

connections as per
