Q501 4 Cylinder MT Application

DTC Troubleshooting Data

Version: 0.1

Date: 21-Sep-2018

Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta

Checked By: Yogesh Jadhav

Approved By: Satish Kumar P

Page: 550 of 1052

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

DTC’s confirmation

(checks before handing over vehicle to customer)

•

After rectification, ensure the following points by referring engine parameters using TML diagnostic tool before

handing over to customer.

•

Clear the DTC, Turn OFF the ignition and then turn it ON. Read the DTC’s. Ensure that fault shall not reappeared.

Circuit Schematic:

Component Location & Image:-

Connector View & Information: -
