Step Checks
IF YES
IF NO
1.
Is the Inlet Air Circuit Clogged
Rectify / Replace the
Air inlet circuit
Go to Step 2
2. Are any of the faults of Boost pressure sensor
Rectify these faults
by following their
rectification
procedure3
Go to step 3
3
Is there any rust/oxidization observed on Sensor Terminals
Clean the Rust or
repair or replace
Go to step 4
4
Is there wiring harness electrical continuity between ECU
pins A38, A96,7 Boost pressure Sensor connector pins 1,
4
Go to Step 5
Establish continuity
by rectifying
harness
connections as per
the circuit
schematic
5
Are there any pins damaged at Sensor/EMS ECU
Connector
Replace the
connector or wiring
harness
Go to step 6
6
Are there any pins backed out from the Sensor/EMS ECU
Connector
Rectify/Replace
Connectors
Go to Step 7
7
Is Sensor Supply pin A96, Short circuited to GND/Battery.
Repair the harness
as per the schematic
Go to Step 8
8
Is Sensor Signal Pin A61, Short circuited to GND/Battery
Repair the harness
as per the schematic
Go to Step 9
9
Is sensor physically Damaged
Replace Sensor
Go to Step 10
10 Is the VGT valve / EGR valve mechanically damaged
Rectify/Replace the
VGT valve
Go to step 11
11 Is the Turbo charger physically damaged
Rectify/Replace the
turbo charger
Go to step 12
12 Fault Still Persists?
Call Hotline.
Follow the steps
again for
reconfirmation
DTC’s confirmation:
After rectification, Test Drive the vehicle for 2 KM and ensure that no DTC’s are logged in ECM.
