P1B11-46: Torque to quantity conversion not strictly monotonous (calibration / parameter memory failure)

Overview:

DTC Description as per ISO standard

Torque to quantity conversion not strictly monotonous

(calibration / parameter memory failure) - calibration /

parameter memory failure

ECU Pin Number

Customer Symptom

MIL ON

Fault Effects (On Vehicle)

No limp home

Lamp Status (If Any)

MIL ON

Fault Detection Condition (Root cause)

Ignition on engine on vehicle running

Normal Operating Condition

No Fault Code

Probable Trouble Area

Transmission clutch not release.

Engine mechanical failure

Healing Condition

Write IMA code.

Clear through diagnostic tool

Ignition OFF & ON

Component Details: NA

Preliminary Checks:

1. Check whether the customer voice / view about the issue is matching with the fault effects mentioned above. If

Yes, go ahead with next steps. If not, check for other DTC’s presence.

2. Check whether similar complaints are earlier reported. If yes, perform the preliminary checks with respect to

earlier issue closure.

3. Check for any other faults presence related to ECU Internal power supplies; Follow rectification process for those

faults, before proceeding further.

4. Check for electrical continuity between ECU to AMF connector as per circuit schematic and rectify electrical

discontinuity if noticed.

5. Check inlet air circuit for clogging; wrong assembly/fitment etc; Clean the inlet air circuit and remove any clogging.

Trouble Shooting:
