Immobilizer –DTC Troubleshooting Data

Version: 1.

2

Date:

03-June-2014

Prepared Author

:

Sarang K/Mithipati P

Review & approved by

: R A Rode (ERC-E&E)

Page: 59 of 67

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

B163A-14: Vehicle immobilizer control module Status Indicator short to Ground or Open Circuit

Overview:

ISO Code

B163A-14

DTC simple Description

Immobilizer Status LED short to ground or Open Circuit

Customer Symptom

No impact on functioning but status LED remains ON

Fault Effects (On Vehicle)

No Impact

Lamp Status (If Any)

Off

Fault Detection Condition

At ignition On

Normal Operating Condition

Authentication between EMS & Immo is successful

Probable Trouble Area

w/h, immo, instrument cluster

Healing Condition

Off

Component Details:

Immobilizer system is designed to prevent vehicle theft by electronically disabling the engine starting system. The

engine can be started only with vehicle’s original immobilizer ignition key, which has an electronic identification

programmed code. Immobilizer unit is an add-on part on the ignition switch, fitted on the steering column. The

engine can be started only with the vehicle’s original immobilizer ignition key. The electronic key communicates

the identification code to ICU when the key is turned to the "Ignition ON" position.

Preliminary Checks:

Not applicable

Trouble Shooting:-

Step Checks

IF YES

IF NO

1

Check the continuity between immo pin 5 & instrument

cluster pin 20 any open circuit or short to ground.

Rectify fault

Go to next step

2

Change the instrument cluster

Go to next step

3

Replace the immobilizer

DTC’s confirmation:-

Before handover to customer, ensure that vehicle will start without any error

Circuit Schematic Diagram:

Please refer the immobilizer circuit schematic

VICM

pin no

Pin description

1

Vbatt (KL30)

2

GND

3

CAN_H(High-speed)

4

Ignition (KL15)

5

Status LED

6

Trasport Mode Fuse (10A)

7

Battery Supply (+Vbatt)

8

CAN_L(High-speed)

Component Location & Image:-
