Immobilizer –DTC Troubleshooting Data
Version: 1.
2
Date:
03-June-2014
Prepared Author
:
SK
Review & approved by
: R A Rode (ERC-E&E)
Page: 37 of 67
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:-
Voltage
fluctuates
between 0V and
14V?
A
Yes
Disconnect VICM ECU power supply
connector. Check voltage b/w pin 1& 2.
(Refer Connector View & Information)
No
Is DTC
Present?
Yes
No
Stop
1. Connect the TML Diagnostic Tool.
2. Turn the Ignition ON
3. Check the status of DTC’s (Memorized/Current)
4. Record the DTC & Clear
5. Turn Ignition OFF & ON.
6. Read ECU parameters using diagnostic tool
Range: 9 to 16 V.
7. Verify If
U3006 – 17
is present
Replace wiring harness
(Vehicle side)
Check resistance of Under bonnet fuse
box (60 Amp).
Is it infinity
/Showing No
value (fuse is
blown)?
Yes
No
Replace the respective
fuse
A
