B100C-86:- Driver Side Peripheral sensor signal invalid

Overview:-

ISO Code

B100C86

Customer Symptom

SRS Warning Lamp continuously ON in Instrument Cluster.

Fault Effects (On Vehicle)

Driver Side Crash detection performance is degraded &

Driver Side angular crash detection is not guaranteed.

Lamp Status (If Any)

SRS Warning Lamp continuously ON in Instrument Cluster.

Fault Detection Condition

This fault gets logged if an invalid signal is obtained from Driver

Side peripheral Sensor.

Normal Operating Condition

Proper signal should be obtained from Driver Side peripheral

Sensor.

Probable Trouble Area

Related wiring Harness, connector or terminals

Driver Side peripheral Sensor.

Airbag Wiring Harness

Airbag ECU

Healing Condition

Airbag ECU & Wiring Harness should be checked for any shorts,

bents or damage & it needs to be rectified.

Component Details:-

Driver Side peripheral Sensor

: - These sensors are mounted on right side “B” pillar at the bottom end.

Airbag ECU

: - It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) c ontrols the

deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the Driver and

passengers.

Preliminary Checks:-

1. Check Battery Voltage (12 V & above)

2. Check for any faults in Airbag Warning Lamp indication in Instrument Cluster.

3. Ensure the proper locking of Airbag ECU wiring harness connectors in the vehicle by the locking sound.

Check whether the Driver side peripheral sensor is connected properly to the wiring harness. Ensure

the proper locking of the Driver side peripheral sensor to the wiring harness connector.

Trouble Shooting:-
