B100C-2B:- Driver Side Peripheral sensor signal cross coupled
Overview:-
ISO Code
B100C2B
Customer Symptom
SRS Warning Lamp continuously ON in Instrument Cluster.
Fault Effects (On Vehicle)
Driver Side Crash detection performance is degraded &
Driver Side angular crash detection is not guaranteed.
Lamp Status (If Any)
SRS Warning Lamp continuously ON in Instrument Cluster.
Fault Detection Condition
This fault gets logged if the signal of Driver Side peripheral
Sensor gets cross coupled (cross connected) with any other
sensor terminal during Power ON.
Normal Operating Condition
No cross coupling should be present.
Probable Trouble Area
Related wiring Harness, connector or terminals
Driver Side peripheral Sensor
Airbag ECU
Airbag Wiring Harness
Healing Condition
Cross coupling should be removed & Ignition should be turned
OFF & ON.
Component Details:-
Driver Side peripheral Sensor
: - These sensors are mounted on right side “B” pillar at the bottom end.
Airbag ECU
: - It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) controls the
deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the Driver and
passengers.
Preliminary Checks:-
1. Check Battery Voltage (12 V & above)
2. Check for any faults in Airbag Warning Lamp indication in Instrument Cluster.
3. Ensure the proper locking of Airbag ECU wiring harness connectors in the vehicle by the locking sound.
Trouble Shooting:-
