SRS / Airbag

ECU – DTC Troubleshooting Guide

Version: 14.0

Date: 14-February-2017

Prepared by:Airbag COC Review &

Approved by:Sanjeev VM

Page: 307 of 549

CHAMBER A

Pin

No.

Pin Name

Description

CAN_H

CAN High

CAN_L

CAN Low

A_GND

Common Switch GND

12 V bat

Supply Voltage Battery

23 GND

Power GND

Pin

No.

Pin Name

Description

16 Driver Side

Airbag-

Driver Side Passenger Airbag,

Minus

15 Driver Side

Airbag+

Driver Side Passenger Airbag, Plus

Please refer Airbag ECU Pin Assignment on

or more details.

Inspection Method:-

N.A.

CHAMBER B
