B00D5-14:- Restraint System Passenger Disable Indicator circuit short to ground or open

Overview:-

ISO Code

B00D514

Customer Symptom

SRS Warning Lamp continuously ON in Instrument Cluster

Fault Effects (On Vehicle)

PADI Lamp gives wrong status of Passenger Airbag

Deactivation Switch.

Lamp Status (If Any)

1. SRS Warning Lamp continuously ON in Instrument Cluster.

2. PADI will always be ON, irrespective of PAD Switch status.

Fault Detection Condition

1. PADI device is configured in EOL, but physically not

present in the vehicle.

2. PADI device is open or short to ground

Normal Operating Condition

1. Correct system configuration should be present in Airbag

ECU as per the VC.

2. PADI device should be present in vehicle.

3. Short to ground should not be present for PADI device.

Probable Trouble Area

Related wiring Harness, connector or terminals

PADI Hardware

System Configuration

Airbag ECU

Healing Condition

1. Correct System configuration should be written to Airbag

ECU as per VC.

2. Short to ground for PADI should be removed.

Component Details:-

Airbag ECU

:- It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) controls

the deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the driver

and passengers.

PADI

(Passenger Airbag Deactivation Indicator):- Passenger Airbag Deactivation Indicator is provided in the Fascia

Switch or in SBR display & gives the visual indication to the occupants on the deactivation status of the Passenger

Airbag. This indication will glow, if the Passenger Airbag is deactivated.

PADS

(Passenger Airbag Deactivation Switch):- Passenger Airbag Deactivation (PAD) Switch is provided on the left

side of dashboard. Passenger Airbag should be deactivated if a child is seated in the Front Passenger seat (Since, in

case of an impact, the deployed airbag will hit the child directly on his head with a heavy force, which can be

dangerous to the child). Passenger Airbag can be deactivated by turning the PADS switch in anti-clockwise direction

using the Ignition Key. It can be re-activated by turning the PADS switch in clockwise direction using the Ignition key.

SBR Display

:- SBR (Seat Belt Reminder) display gives visual indication to the occupants regarding the Seat belt

buckle status of front & rear passengers & also the PAD Switch status.

Preliminary Checks:-

1. Check Battery Voltage (12 V & above)

2. Check for any faults in Airbag Warning Lamp indication in Instrument Cluster.

3. Ensure the proper locking of Airbag ECU wiring harness connectors in the vehicle by the locking sound.

Trouble Shooting:-
