SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 208 of 549
Connector View & Information:-
Fig:194 IPC ECU side connector diagram
Airbag ECU is fitted in the floor of central console in the car.
.
:-
Fig:192 Airbag ECU location Fig:193 Airbag Wiring Harness connector
