B1011-00:- Front Deployment Crash no sub type information

Overview:-

ISO Code

B101100

Customer Symptom

SRS Warning Lamp continuously ON in Instrument Cluster.

Fault Effects (On Vehicle)

Crash detection is frozen.

Lamp Status (If Any)

SRS Warning Lamp continuously ON in Instrument Cluster.

Fault Detection Condition

This DTC gets logged if a front deployment crash happens.

Normal Operating Condition

Front Deployment Crash DTC should not be present.

Probable Trouble Area

Airbag ECU.

Healing Condition

Replace the Airbag ECU with the new one (ensure the correct

configuration as per VC).

Component Details:-

Airbag ECU

:- It is fitted in the floor of central console in the car. The Airbag Electronic Control Unit (ECU) controls the

deployment system to allow an appropriate igniting of the Airbags and belt pre-tensioners to restrain the driver and

passengers.

Preliminary Checks:-

1. Check Battery Voltage (12 V & above)

2. Check for any faults in Airbag Warning Lamp indication in Instrument Cluster.

rouble Shooting:-
