SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 154 of 549
Connector View & Information:-
Fig151:- Passenger Front Impact Sensor connector view.
Fig152:- Airbag ECU connector interface.
Airbag ECU is fitted in the floor of central console in the car.
.
Fig:149 Airbag ECU location Fig:150 Airbag Wiring Harness connector
