SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 110 of 549
Pin
No.
Pin Name Description
1 CAN_H CAN High
2 CAN_L CAN Low
7 A_GND Common Switch GND
12 Vbat Supply Voltage Battery
23 GND Power GND
CHAMBER B
5 Driver FIS+ Driver Front Impact Sensor, Plus
6 Driver FIS- Driver Front Impact Sensor, Minus
Please refer Airbag ECU Pin Assignment on or more details.
Inspection Method:- N.A.
CHAMBER A
