B1F3D-71:- Air Distribution Motor Drive Line– Actuator stuck;
ISO Code
B1F3D- 71
Customer Symptom
No air distribution (mode) control (manual or automatic)
Fault Effects (On Vehicle)
The motor is blocked and its motion toward either end is
not possible
Lamp Status (If Any)
Motor shall be disabled
Fault Detection Condition
Mode Door Control Motor - Actuator stuck
Normal Operating Condition
With the Mode motor drive line connected to the harness
and with Ignition ON, check the voltage between blue
connector pin no 5 & ground or 21 & ground of the
Connector. The voltage range should be in between 0 to 14
V
Probable Trouble Area
Motor is stuck because of a mechanical block or
obstruction in movement of flap
Healing Condition
Perform ignition ON/OFF for 11 Cycles for Auto Calibration
Component Details:
The Mode Door Actuator controls the direction of airflow. It selects which way air flows through the different ducts.
Preliminary Checks:
Switch On the IGN & perform the following check.
1)
Connect the Diagnostics tool & check the DTC fault code
2)
If the fault code exists, refer the corrective actions
