B1F48 -13
Air Distribution Feedback Power Supply –
Circuit Open
148
NO
B1F2E-13
Air Distribution Motor Drive Line – Circuit
Open
152
NO
B1F21-15
Air Distribution Feedback Signal – Circuit
Short to battery or Open
156
NO
B1F21-11
Air Distribution Feedback Signal – Circuit
Short to Ground
159
NO
B1F1B-15
Solar Radiation Sensor Circuit - Circuit
short to battery or open
163
NO
B1F1B-11
Solar Radiation Sensor Circuit - Circuit
short to Ground
171
NO
B1F1B-11
Solar Radiation Sensor Circuit - Circuit
short to Ground
170
NO
U3006 - 16
- Control Module Input Power “A” –
Circuit Voltage below Threshold
175
NO
U3006 - 17
- Control Module Input Power “A” –
Circuit Voltage above Threshold
179
NO
P0604 - 00
Internal Control Module Random Access
Memory (RAM) Error
183
NO
P0605 - 00
Internal Control Module Read Only
Memory (ROM) Error
185
NO
P0602 - 57
Control Module Programming Error -
Invalid / Incompatible Software
Component
189
NO
U3007 - 16
Control Module Input Power “B” – Circuit
Voltage below Threshold
192
NO
U3007 - 17
- Control Module Input Power “B” –
Circuit Voltage above Threshold
196
NO
U0028-13
Vehicle Communication Bus A-open
circuit
203
NO
U0028-88
Vehicle Communication Bus A-Bus off
206
NO
U0100-08
Lost communication with ECM- Message
Timeout Failure
208
NO
U130B-08
Lost communication with Head Unit- HU
Message Time Out Failure
214
NO
U0155-08
Lost communication with instrument
Panel Cluster- IPC Message Time Out
Failure
218
NO
U0140-08
Lost communication with Body Control
Module- Message Timeout Failure
222
NO
U0401-81
Invalid Data Received From ECM
228
NO
U0423-81
Invalid Data Received From IPC
231
YES
