Appendix
DisplayDTCCode
DTCDescription
PageNo
Display
Status (Mask
status)(Y/N)
B1F2B-12
Air Conditioning Compressor Request –
circuit short to battery
6
NO
B1F2B-11
Air Conditioning Compressor Request –
circuit short to Ground
9
NO
B1F3E-71
Temperature Door Control Motor -
Actuator stuck
12
NO
B1F3E-54
Temperature Door Control Motor
Calibration Fault
16
NO
B1F2D-12
Temperature Door Control Motor Drive
Line - Circuit Short to Battery
20
NO
B1F2D-11
Air Temperature Motor Drive Line- Circuit
Short to Ground
24
NO
B1F2D-13
Air Temperature Motor Drive Line- Circuit
Open
28
NO
B1F47-13
Air Temperature Feedback Power Supply-
Circuit Open
32
NO
B1F20-11
Air Temperature Feedback Power Supply-
Circuit Short to Ground
36
NO
B1F20-12
Air Temperature Feedback Power Supply-
Circuit Short to Battery
40
NO
B1F1F-15
Air Temperature Feedback Signal - Circuit
Short to Battery or Open
44
NO
B1F1F-11
Air Temperature Feedback Signal - Circuit
Short To Ground
48
NO
B1F2F-13
Blower Motor Drive Signal - Circuit Open;:
52
NO
B1F28-12
Blower Motor Diagnostic Feedback OR
Blower Motor DTC - Circuit Short to
Battery
55
NO
B1F28-14
Blower Motor Diagnostic Feedback -
Circuit Short to Ground or Open
58
NO
B1F2F-12
Blower Motor Drive Signal - Circuit Short
to battery
61
NO
B1F2F-11
Blower Motor Drive Signal - Circuit Short
to Ground
64
NO
B1F2A-12
Cabin Temperature Sensor - Circuit Short
to Battery
67
NO
