5
Mot +
Motor signal is + in
CW and Motor
signal is - in CCW
Digital
6
Mot -
Motor signal is - in
CW and Motor
signal is + in CCW
Digital
Inspection Method: -
1)If there is no continuity between the Fresh/RECIRC door potentiometer supply line & ECU
connector then correct the wiring harness
2) If there is a continuity between the Fresh/RECIRC door potentiometer supply line and Ground line, correct the wiring
harness (wiring harness short to Ground)
