DTC Troubleshooting Data
Version: 2.0
Date: 28-Jul-17
Author: ERC
Page: 101 of 244
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
CW and Motor
signal is - in CCW
6
Mot -
Motor signal is - in
CW and Motor
signal is + in CCW
Digital
Inspection Method: -
1) If there is a continuity between the Fresh/RECIRC potentiometer supply line and Battery line correct the wiring harness
(wiring harness to Battery)
