PIN Assignment
C1
ACTUATOR
Amp no 0-
1355082-1
1
PotentiometerGnd
Potentiometer
Ground with FB-
Gnd
2
PotentiometerFbSig
Potentiometer
feedback signal
Analog
3
PotentiometerSpply
Potentiometer
Supply with FB-
Power
4
5
Mot +
Motor signal is + in
CW and Motor
signal is - in CCW
Digital
6
Mot -
Motor signal is - in
CW and Motor
signal is + in CCW
Digital
Inspection Method: -
2) If there is a continuity between the Temperature feedback line and Battery line correct the wiring harness (wiring
harness short to Ground)
