{Osprey CCM}

DTC Troubleshooting Data

Version: 2.0

Date: 28-Jul-17

Author: ERC

Page: 39 of 244

Copyright ©

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

PIN Assignment

C1

ACTUATOR

Amp no 0-

1355082-1

1

PotentiometerGnd

Potentiometer

Ground with FB-

Gnd

2

PotentiometerFbSig

Potentiometer

feedback signal

Analog

3

PotentiometerSpply

Potentiometer

Supply with FB-

Power

4

5

Mot +

Motor signal is + in

CW and Motor

signal is - in CCW

Digital

6

Mot -

Motor signal is - in

CW and Motor

signal is + in CCW

Digital

Inspection Method: -

1)If there is no continuity between the Temperature door potentiometer supply line & ECU connector then correct the

wiring harness

2) If there is a continuity between the Temperature door potentiometer supply line and Ground line, correct the wiring

harness (wiring harness short to Ground)
