Troubleshooting:-
Start
Connect the Diagnostic Tool and check for DTCs
Is DTC B1032 – 62
present?
STOP
Check DTC present is Current or history
Yes
History?
Yes
Is DTC B1032 –
62 present?
C
Yes
C
Is vehicle getting cranked OR
vehicle powermode changed ?
ESCL Faulty
Reset ESCL with diagnostics command (hard reset-
11 01) and try to start vehicle OR press start stop
switch to change state from OFF to IGN.
1. Clear the DTC from memory.
2. Turn the IGN to OFF.
3. Start the IGN.
4. Check for DTCs.
No
Replace ESCL
No
Yes
No
No
