Troubleshooting:-
Start
Connect Diagnostic tool and Check for DTCs.
Is
DTC U1614 – 62
present?
Yes
Stop
No
Check DTC present is Current or Historic
Is
History?
Yes
No
1. Clear the DTC from memory.
2. Provide IGN cycle.
3. Turn IGN OFF.
1. Provide Hard reset to PEPS & IC.
2. Provide IGN cycle.
3. Turn IGN OFF.
Is
DTC U1614 – 62
present?
Yes
PEPS ECU faulty
Reconnect previous IC & re-flash
PEPS ECU, if problem still
remains than check for memory
related fault and follow it. If not
memory fault present than
replace PEPS ECU.
No
Use another working IPC
(Refer IPC replacement procedure document)
1. Provide Soft reset to PEPS & IC.
2. Provide IGN cycle.
3. Turn IGN OFF.
Is
DTC U1614 – 62
present?
Yes
No
Is
DTC U1614 – 62
present?
Yes
No
Refer IPC troubleshooting
Guide.
