HARRIER BOOK 2

PEPS Part ReplacementProcedure

Title: PEPS System Part Replacement Procedure

Spec Num 2921 XX XXX A XXXXTBD

Date:

28-Jul-18

Version:

1.5

Page: 15 of 25

Prepared:

Sandip

Checked:

Santosh B

Approved:

Dinesh DG

Thisspecification isthe exclusive property of Tata MotorsLimited. Withouttheir consent it may not be reproduced or given to third

parties

The above specificationsare subject to change and therefore suppliersare requested to refer the latest one.

CONTROLLED COPY FOR RESTRICTED CIRCULATION

2.3.

Smart key orWearable learningprocedure

NOTE:

Please note procedure of learning wearable and smart key is same. Whenever

required, keep wearable near to console antenna same way you are keeping smart key near to

console antenna.

Prerequisite:

All smart keys and wearable (if any) to be learnt shall be available.

NOTE:

1) Total numbers of smart keys or wearable to be learnt are considered as 2.

2) Indicated operational steps along with timings to be followed else learning operation will fail.

PROCEDURE:

1) No IGN ON is mandatory to learn smart key or wearable with PEPS ECU. Only PEPS ECU

shall be in awake mode which shall be achieved by turning and keeping ONposition lamps

or hazard lamps till learning is done.

2) If fresh ECU is present, Free IGNON are available i.e. user can turn ON IGN without smart

key or wearable is learned for 25 times.

3) Place the Smart Key or wearable to be learnt within 7 cm around the front / console

antenna.

4) Run “Start transponder learning routine initial” through diagnostics. PEPS check the validity

of the key or wearable. Refer latest PEPS ESDS for detailed procedure.

5) If above steps is OK, all previous learned smart keys and wearable data are deleted (if

any). Immobilizer lamp start blinking (ON=0.1sec, OFF=0.4sec) indicating that PEPS is

learning the smart key or wearable.

6) Once respective key or wearable is learnt, Immobilizer lamp remains ON indicating that

PEPS has learnt the key. Refer latest PEPS ESDS for detailed procedure.

7) If next key or wearable to be learnt,

a) Remove already learnt key or wearable from console antenna area and place next

key to be learnt within 10 sec.

b) Once respective key or wearable is learnt, Immobilizer lamp remains ON indicating

that PEPS has learnt the key or wearable.
