ESP DTC Troubleshooting Data
Version: 1.0
Date: 23-Oct-15
Author: ERC, Chassis E&E CoC
Page: 197 of 224
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Trouble Shooting:
START
1. Turn OFF ignition
2. Wait for 5 seconds
3. Turn ON ignition
4. Connect the diagnostics tool and Read Logged DTCs
Is U0102-08
logged in
current state?
Do necessary repairs in the wiring harness.
1. Check if VCC and Ground of TCC is properly
connected
2. Check for any blown/disconnected fuse at VCC
line of TCC connector
Is continuity
there?
1. Check for continuity between
TCC CAN_H to IPC CAN_H & TCC CAN_L to IPC
CAN_L in vehicle wiring side connector
Do necessary repairs in the wiring harness.
Clear DTC
STOP
Y
Y
N (In History)
N
