Step Checks
IF YES
IF NO
1.
Remove Inlet Diesel Particulate Filter exhaust gas
temperature sensor 2 connector.
Go to Step 2.
-
2.
Identify the pin number on the harness side connector.
Go to step 3.
-
3.
Check the continuity between pin 1 of the harness side
connector and battery Positive. If continuity is there than
there is short to batt.
There is a short
circuit in the harness
and perform repairs
accordingly.
Go to step 4.
4.
Disconnect the connector.
Identify the pin number 1 on
the harness side connector. Check the continuity between
pin 1 of the harness side connector and battery Positive. If
the continuity is not observed then there is an open circuit
means signal is missing.
There is a short
circuit in the harness
and perform repairs
accordingly.
Go to step 5.
5.
Are there any pins damaged at Sensor/EMS ECU
Connector.
Replace the
connector or wiring
Harness.
Go to step 6.
6.
Are there any pins backed out from the Sensor/EMS ECU
Connector.
Rectify/Replace
Connectors.
Go to Step 7.
7.
Is sensor physically Damaged?
Replace Sensor.
Go to Step 8.
8.
If fault still persists.
then replace sensor
and if fault still
persists then call
Hotline.
Follow the above
procedure again for
Reconfirmation.
DTC’s confirmation
(checks before handing over vehicle to customer)
:
1. Check the errors at Ignition ON, engine running @ Idle & Fly-up with different vehicle speeds also.
2. If error present, then rectify the errors.
3. Confirm that there is no error logged in EMS before handing over vehicle to customer.
